Factory Stock
Used in conjunction with system pressure switch–can warn of a fault while allowing lube system to continue to deliver to critical bearings.
Requires replacement of the rupture disc to restart the lube system.
Easy information on blocked lines, high system pressure or blocked bearings.
Replacement Rupture Packs of 6 (11/16 inch / 17.5 mm diameter discs)
2,050 psi - orange
| Dimensions | |
|---|---|
| Unit Height | 0.2 (in) |
| Unit Length | 4.25 (in) |
| Unit Volume | .00123 (ft³) |
| Unit Weight | 0.05 (lb) |
| Unit Width | 2.5 (in) |
| Attributes | |
|---|---|
| UPC Code | 00633955335042 |
| Color | Orange |
| Maximum Working Pressure | 141 (bar) |
| Maximum Working Pressure | 14125 (kPa) |
| Maximum Working Pressure | 14.1 (MPa) |
| Maximum Working Pressure | 2050 (psi) |
| Number of Pieces | 6 |
| Overall Diameter | 1.7 (cm) |
| Overall Diameter | 0.688 (in) |
| Overall Diameter | 17 (mm) |
| Type | Rupture Disk |
