graco-19Y592-19Y592

GRACO
19Y592

$1,645.00

This kit makes it easy to replace an existing rotary vane motor on a 5 gallon (18 liter) or 10 gallon (38 L) pail agitator with a radial piston air motor.

  • GRACO
  • Material:19Y592
  • Model:KIT,RETRO,5-10 GA PAIL,RP MTR
  • Summary:This kit makes it easy to replace an existing rotary vane motor on a 5 gallon (18 liter) or 10 gallon (38 L) pail agitator with a radial piston air motor.

Factory Stock

Graco 19Y592 Radial Piston Air Motor Retrofit Kit for 5 gallon (18 L) or 10 gallon (38 L) pail agitators. Pail cover, agitator shaft and blade not included.
  • Radial piston air motor driven agitators are reliable, simple and cost-effective solutions for low to medium speed (<500 rpm), low to medium viscosity (<1000 cp) agitation applications.
  • Air line lubrication not required
  • Easy to maintain and service
  • Sound pressure level at 70 psig (maximum recommended speed): Less than 75 dBA
  • Pail cover, agitator shaft and blade sold separately

For wood (top coat, primer) and general finishing applications
Dimensions
Unit Length 14 (in)
Unit Volume .729167 (ft³)
Unit Weight 9 (lb)
Unit Width 11.25 (in)
Unit Height 8 (in)

Attributes
Type Conversion Kit
Motor Type Pneumatic - Radial Piston
Maximum Working Pressure 70 (psi)
Maximum Working Pressure 500 (kPa)
Maximum Working Pressure 5 (bar)
Maximum Speed 150 (RPM)
Maximum Air Inlet Pressure 70 (psi)
Maximum Air Inlet Pressure 500 (kPa)
Maximum Air Inlet Pressure 5 (bar)
Air Inlet Thread Type NPT
Air Inlet Size 6.35 (mm)
Air Inlet Size 1/4 (in)
Air Inlet Size 0.635 (cm)
UPC Code 00769946032208
