graco-HEM004-HEM004
graco-HEM004-HEM004

GRACO
HEM004

Price: $650.00

Sale: $552.50

Price too low to display!
See price in cart.

Graco’s industrial-grade LDX hose reel offers incredible value for cost-conscious workshops. Its all-metal frame and specially crafted, long-lasting components provide consistent release and retraction.

  • GRACO
  • Material:HEM004
  • Model:LDX SERIES REEL,HOSE,1/2" X 50',OIL
  • Summary:Graco’s industrial-grade LDX hose reel offers incredible value for cost-conscious workshops. Its all-metal frame and specially crafted, long-lasting components provide consistent release and retraction.

Factory Stock

Graco HEM004 LDX™ Series, Oil, 1/2 in (13 mm) Inlet, 1/2 in X 50 ft (13 mm X 15 m) Hose, NPT
  • Dual Pedestal Frame - Ribbed metal for increased stability and robustness.
  • External Swivel Housing - Quickly access swivel seal for faster repairs.
  • Ball Bearing Swivel - Swivel designed with internal ball bearings reduces friction and ensures smooth operation.
  • Adjustable Arm - Easily change to one of six arm positions to fit your application.
  • Large Hose Capacity with Small Profile - Compact design accommodates up to a 50 foot (15 meter) hose to meet a wide variety of application requirements.

Designed for smaller garages, independent repair facilities and industrial manufacturing environments.
Dimensions
Unit Length 20.875 (in)
Unit Volume 2.973487 (ft³)
Unit Weight 55 (lb)
Unit Width 11.125 (in)
Unit Height 22.125 (in)

Attributes
Minimum Temperature -40 (°F)
Includes Hose Yes
Mount Location Truck Mount;Bench Mount
Outlet Size 1/2 (in)
Outlet Size 12.7 (mm)
Outlet Thread Gender Male
Outlet Thread Type NPT
Overall Height 19 (in)
Overall Height 483 (mm)
Overall Length 17.5 (in)
Overall Length 445 (mm)
Overall Width 9.4 (in)
Overall Width 239 (mm)
Recommended Environment Indoor
Recommended Fluid Type Oil
Reel Thread Type NPT
Type Spring-Rewind Reel
Wetted Parts Zinc-Plated Steel;Brass;Polyurethane;Nitrile Rubber
Hose Length 15 (m)
UPC Code 00769946211924
Model LDX
Application Oil
Color Grey
Dry Weight 48 (lb)
Frame Type Dual Pedestal
Hose Inside Diameter 1/2 (in)
Hose Inside Diameter 12.7 (mm)
Hose Length 50 (ft)
Minimum Temperature -40 (°C)
Hose Reel Type Reel with Hose
Inlet Size 1/2 (in)
Inlet Size 12.7 (mm)
Inlet Thread Gender Male
Inlet Thread Type NPT
Maximum Temperature 100 (°C)
Maximum Temperature 212 (°F)
Maximum Working Pressure 1500 (psi)
