graco-119577-119577

GRACO
119577

$1,125.00

Drain, evacuate and transfer used oil (and other used fluids) reliably, quickly and in the most cost-effective manner.

  • GRACO
  • Material:119577
  • Model:RECEIVER, OIL
  • Summary:

    Drain, evacuate and transfer used oil (and other used fluids) reliably, quickly and in the most cost-effective manner.

Quantity in stock: 1

Graco 119577 24 gal (90 l) Steel-Tank Pressurized Oil Drain
  • Ensures peak performance with easy-to-read vacuum gauge
  • Includes vacuum probes with a variety of suction attachments and adapters
  • Features a 24-gallon (90 L) capacity receiver
  • Includes optional large offset collection pan to prevent splashing
  • Uses shop air to pressurize for easy oil evacuation and draining
  • Includes optional sight glass, which allows for oil quality inspection with clear evacuation chamber and easy-to-read evacuation measurements

For shops requiring flexibility, use Graco’s multi-purpose used oil evacuation system when fluid drain plugs are either not easily accessible or not available.
Dimensions
Unit Length 1.2 (in)
Unit Volume .001 (ft³)
Unit Weight 67 (lb)
Unit Width 1.2 (in)
Unit Height 1.2 (in)

Attributes
Wetted Parts Steel;Copper;PVC Plastic;Rubber;Aluminum
Weight 74 (lb)
Weight 33.57 (kg)
Type Fluid Reclamation Package
Tank Capacity 90 (L)
Tank Capacity 24 (gal)
Overall Width 406 (mm)
Overall Width 0.41 (m)
Overall Width 16 (in)
Overall Width 1.3448 (ft)
Overall Width 40.6 (cm)
Overall Height 2032 (mm)
Overall Height 2.03 (m)
Overall Height 80 (in)
Overall Height 6.67 (ft)
Overall Height 203.2 (cm)
Maximum Working Pressure 7 (psi)
Maximum Working Pressure 50 (kPa)
Maximum Working Pressure 0.5 (bar)
Compatible Fluid Oil
Color Black
UPC Code 00633955100138
