Graco's LD Series DEF solutions offer long-lasting efficiency in a compact, high-performance electric pump package capable of pumping up to 9 gpm (34 lpm). Whether a small garage, large dealership, or heavy equipment maintenance facility, Graco has a complete line of Diesel Exhaust Fluid (DEF) products for every application. Our electric, pneumatic, or manual products are engineered specifically for the advanced needs of DEF fluid and are designed to minimize downtime and dispense materials quickly without compromising chemical integrity.
Graco's LD Series DEF solutions offer long-lasting efficiency in a compact, high-performance electric pump package capable of pumping up to 9 gpm (34 lpm). Whether a small garage, large dealership, or heavy equipment maintenance facility, Graco has a complete line of Diesel Exhaust Fluid (DEF) products for every application. Our electric, pneumatic, or manual products are engineered specifically for the advanced needs of DEF fluid and are designed to minimize downtime and dispense materials quickly without compromising chemical integrity.
Factory Stock
| Dimensions | |
|---|---|
| Unit Length | 17.7 (in) |
| Unit Volume | .2617 (ft³) |
| Unit Weight | 2.415 (lb) |
| Unit Width | 7.3 (in) |
| Unit Height | 3.5 (in) |
| Attributes | |
|---|---|
| Meter Technology | Turbine |
| Wetted Material | Stainless Steel;Plastic;Rubber |
| Metering Gun Weight | 0.08 (kg) |
| Metering Gun Weight | 1.8 (lb) |
| Minimum Operating Temperature | -10 (°C) |
| Minimum Operating Temperature | 14 (°F) |
| Nozzle Type | Rigid |
| Overall Height | 19.0144 (cm) |
| Overall Height | 7.4860 (in) |
| Overall Height | 190 (mm) |
| Overall Length | 40 (cm) |
| Overall Length | 15.6024 (in) |
| Overall Length | 396 (mm) |
| Overall Width | 8 (cm) |
| Overall Width | 3.152 (in) |
| Overall Width | 80 (mm) |
| Recommended Environment | Indoor |
| Trigger Lock | Locking |
| Trigger Protection Type | Guard |
| Type | Automatic Shut-Off Nozzle |
| Warranty | 2 years |
| Inlet Size | 3/4 (in) |
| UPC Code | 00633955599321 |
| Model | LD |
| Compatible Material | Diesel Exhaust Fluid |
| Dispense Type | Manual |
| Display Type | LCD |
| Extension Type | Rigid |
| Fluid Inlet Thread Gender | Male |
| Fluid Outlet Thread Gender | Male |
| Includes | LD Automatic Nozzle with built-in Electronic Turbine Meter;with Stainless Steel Breakaway Tip;Hose Barb |
| Inlet Size | 1.905 (cm) |
| Meter Accuracy | 1 |
| Inlet Size | 19.05 (mm) |
| Inlet Thread Type | BSPP |
| Maximum Operating Temperature | 50 (°C) |
| Maximum Operating Temperature | 122 (°F) |
| Maximum Storage Temperature | 70 (°C) |
| Maximum Storage Temperature | 158 (°F) |
| Maximum Working Pressure | 3.5 (bar) |
| Maximum Working Pressure | 350 (kPa) |
| Maximum Working Pressure | 0.4 (MPa) |
| Maximum Working Pressure | 50 (psi) |
