graco-204254-204254

GRACO
204254

$1,845.00

As the mainstay pump in the industry for decades, the reputation of Fire-Ball is unrivaled. Built to withstand the test of time with fewer moving parts, our flagship pump is built to extend uptime so customers can be more productive. The durable pumps are renowned for their durability, with pumps built decades ago still operating efficiently.

  • GRACO
  • Material:204254
  • Model:FIREBALL 300 PUMP ,5:1,55 GL,BUNG MT
  • Summary:As the mainstay pump in the industry for decades, the reputation of Fire-Ball is unrivaled. Built to withstand the test of time with fewer moving parts, our flagship pump is built to extend uptime so customers can be more productive. The durable pumps are renowned for their durability, with pumps built decades ago still operating efficiently.

Factory Stock

Graco 204254 Fire-Ball 300 Series 5:1 Oil Pump, 55 Gallon (200 Liter) Drum Size - For Bung Mount
  • Reliable Flow - A 3 inch (76.2 mm) differential air motor and the double-acting pump design provides reliable fluid flow and accurate dispense.
  • Durable - Thick cast aluminum air motor housing offers unmatched durability.
  • Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
  • Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
  • Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
  • Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated "dirty" air environments for long life without repair.
  • Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
  • Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

Install the Fire-Ball 300 5:1 in high pressure, medium volume oil transfer applications such as automotive dealerships, fast lube centers, and service shops.
Dimensions
Unit Length 57.6 (in)
Unit Volume 3.456 (ft³)
Unit Weight 29 (lb)
Unit Width 9.6 (in)
Unit Height 10.8 (in)

Attributes
Fluid Outlet Thread Type NPT
Wetted Material Steel;Polyurethane;Aluminum;Buna-N
For Use With Petroleum- and synthetic-based oils (motor, gear and ATF)
Maximum Air Consumption 25 (SCFM)
Maximum Air Inlet Pressure 12.41 (bar)
Maximum Air Inlet Pressure 1241 (kPa)
Maximum Air Inlet Pressure 180 (psi)
Maximum Continuous Cycle Rate 70 (CPM)
Maximum Intermittent Cycle Rate 70 (CPM)
Maximum Working Pressure 62 (bar)
Maximum Working Pressure 6200 (kPa)
Maximum Working Pressure 6.2 (MPa)
Maximum Working Pressure 900 (psi)
Power Type Pneumatic
Pump Ratio 5:1
Sound Power Level 85.6 (dB)
Sound Pressure Level 77.8 (dB)
Type Pneumatic Piston Pump
Weight 0.7718 (kg)
Weight 17 (lb)
Compatible Material Oil
UPC Code 00633955520783
Model Fire-Ball
Series 300
Air Inlet Size 0.9525 (cm)
Air Inlet Size 3/8 (in)
Air Inlet Size 9.525 (mm)
Air Inlet Thread Gender Female
Air Inlet Thread Type NPT
Air Motor Effective Diameter 3 (in)
Application Industrial
Fluid Outlet Thread Gender Female
Cycles Per Gallon 30
Fluid Inlet Size 3.81 (cm)
Fluid Inlet Size 1-1/2 (in)
Fluid Inlet Size 38.1 (mm)
Fluid Inlet Thread Gender Female
Fluid Inlet Thread Type NPT
Fluid Outlet Size 1.27 (cm)
Fluid Outlet Size 1/2 (in)
Fluid Outlet Size 12.7 (mm)
