Hydraulic Power-Star pumps provide reliable, quiet, ice-free performance at maximum pressure and low flow rates and are up to three times more energy efficient than comparable compressed-air systems.
Hydraulic Power-Star pumps provide reliable, quiet, ice-free performance at maximum pressure and low flow rates and are up to three times more energy efficient than comparable compressed-air systems.
Factory Stock
| Dimensions | |
|---|---|
| Unit Length | 34.8 (in) |
| Unit Volume | 2.32 (ft³) |
| Unit Weight | 119 (lb) |
| Unit Width | 9.6 (in) |
| Unit Height | 12 (in) |
| Attributes | |
|---|---|
| For Use With | Petroleum- and synthetic-based oils (motor, gear and ATF) |
| Wetted Material | Iron;Steel;Stainless Steel;Nitrile;Polyurethane |
| Maximum Continuous Cycle Rate | 60 (CPM) |
| Maximum Flow Rate | 12 (GPM) |
| Maximum Flow Rate | 45.42 (L/min) |
| Maximum Fluid Output Pressure | 103 (bar) |
| Maximum Fluid Output Pressure | 1500 (psi) |
| Maximum Hydraulic Fluid Inlet Pressure | 103 (bar) |
| Maximum Hydraulic Fluid Inlet Pressure | 10300 (kPa) |
| Maximum Hydraulic Fluid Inlet Pressure | 1500 (psi) |
| Maximum Intermittent Cycle Rate | 60 (CPM) |
| Pump Ratio | 1:1 |
| Type | Hydraulic Piston Pump |
| Fluid Outlet Thread Type | NPT |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Size | 12.7 (mm) |
| Fluid Outlet Size | 1/2 (in) |
| Fluid Outlet Size | 1.27 (cm) |
| Fluid Inlet Thread Type | NPT |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Size | 38.1 (mm) |
| Fluid Inlet Size | 1-1/2 (in) |
| Fluid Inlet Size | 3.81 (cm) |
| Compatible Material | Oil |
| Application | Industrial |
| Model | Power-Star |
| UPC Code | 00633955172982 |
