graco-237526-237526

GRACO
237526

$6,210.00

With a large 4.25 inch (107.9 mm) air motor to supply the power you need for long pipe runs and higher volume dispensing, the Fire-Ball 425 delivers field-proven durability for multiple fluid types and exceptional cost savings that are hard to beat!

  • GRACO
  • Material:237526
  • Model:FIREBALL 425 PUMP,3:1
  • Summary:

    With a large 4.25 inch (107.9 mm) air motor to supply the power you need for long pipe runs and higher volume dispensing, the Fire-Ball 425 delivers field-proven durability for multiple fluid types and exceptional cost savings that are hard to beat!

Factory Stock

Graco 237526 Fire-Ball® 425 Series 3:1 Universal Size Oil Pump
  • Durable - Thick cast aluminum air motor housing offers unmatched durability.
  • Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
  • Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
  • Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
  • Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated "dirty" air environments for long life without repair.
  • Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
  • Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

The Fire-Ball 425 is the pump of choice for your most demanding high volume applications - an ideal choice for applications such as truck fleet service facilities and in-plant applications where multiple dispenses happen at the same time.
Dimensions
Unit Length 34.8 (in)
Unit Volume 2.349 (ft³)
Unit Weight 48 (lb)
Unit Width 10.8 (in)
Unit Height 10.8 (in)

Attributes
Fluid Outlet Thread Gender Female
Wetted Material Steel;Polyurethane;Aluminum;Nitrile
Fluid Outlet Thread Type NPT
For Use With Petroleum- and synthetic-based oils (motor, gear and ATF)
Maximum Air Inlet Pressure 12.41 (bar)
Maximum Air Inlet Pressure 1241 (kPa)
Maximum Air Inlet Pressure 180 (psi)
Maximum Continuous Cycle Rate 66 (CPM)
Maximum Intermittent Cycle Rate 66 (CPM)
Maximum Working Pressure 37 (bar)
Maximum Working Pressure 3700 (kPa)
Maximum Working Pressure 3.7 (MPa)
Maximum Working Pressure 540 (psi)
Power Type Pneumatic
Pump Ratio 3:1
Sound Pressure Level 82 (dB)
Type Pneumatic Piston Pump
Weight 2.0884 (kg)
Weight 46 (lb)
Application Industrial
UPC Code 00633955320086
Model Fire-Ball
Series 425
Air Inlet Size 1.27 (cm)
Air Inlet Size 0.5 (in)
Air Inlet Size 12.7 (mm)
Air Inlet Thread Gender Female
Air Inlet Thread Type NPT
Air Motor Effective Diameter 4.25 (in)
Fluid Outlet Size 19.05 (mm)
Compatible Material Oil
Cycles Per Gallon 6
Fluid Inlet Size 3.81 (cm)
Fluid Inlet Size 1-1/2 (in)
Fluid Inlet Size 38.1 (mm)
Fluid Inlet Thread Gender Female
Fluid Inlet Thread Type NPT
Fluid Outlet Size 1.905 (cm)
Fluid Outlet Size 3/4 (in)
