graco-246913-246913

GRACO
246913

$3,720.00

You can't afford down time, especially when your shop is small and your work force depends on equipment performance. The Mini Fire-Ball 225 is an engineered design with fewer moving parts, which means less wear out, and reduced downtime and more profit for your business.

  • GRACO
  • Material:246913
  • Model:DISPENSER, CRT MNT,FB 225,50:1,35#
  • Summary:

    You can't afford down time, especially when your shop is small and your work force depends on equipment performance. The Mini Fire-Ball 225 is an engineered design with fewer moving parts, which means less wear out, and reduced downtime and more profit for your business.

Factory Stock

Graco 246913 Mini Fire-Ball® 225 50:1 35 lb. and 50 lb. (16 kg and 23 kg) Grease Pump - Cart-Mounted Pail Dispenser Package
  • Durable - Thick cast aluminum air motor housing offers unmatched durability.
  • Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
  • Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
  • Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
  • Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated "dirty" air environments for long life without repair.
  • Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
  • Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

The Mini Fire-Ball 225 50:1 is perfect for medium pressure, low volume grease applications.
Dimensions
Unit Weight 76.88 (lb)

Attributes
Fluid Outlet Thread Type NPT
Wetted Material Steel;Urethane;Aluminum;Buna-N;Brass;Ethylene;Delrin
Type Piston Pump Package
Pump Weight 15 (lb)
Pump Ratio 50:1
Power Type Pneumatic
Mount Location Cart Mount
Motor Type Pneumatic
Maximum Working Pressure 5000 (psi)
Maximum Working Pressure 35 (MPa)
Maximum Working Pressure 34500 (kPa)
Maximum Working Pressure 345 (bar)
Maximum Air Working Pressure 100 (psi)
Maximum Air Working Pressure 140
Includes Pump;Dispense Kit;Cover;Holste;2-Wheel Truck;CE Kit;Pail
Fluid Outlet Thread Gender Female
Fluid Outlet Size 6.35 (mm)
Fluid Outlet Size 1/4 (in)
Fluid Outlet Size 0.635 (cm)
Fluid Inlet Type Slotted
Compatible Material Grease
Application Industrial
Air Inlet Thread Type NPT
Air Inlet Thread Gender Female
Air Inlet Size 0.375 (in)
Series 225
Model Mini Fire-Ball
UPC Code 00633955117631
