For standard and heavy-duty applications, both indoor and outdoor, the SDV15 control valves are designed to perform in larger dealerships with longer plumbing runs and greater fluid usage. The control valve is compatible with a wide range of nozzles and fluid extensions and is capable of pumping oil up to 15 gpm (56.8 lpm).
Factory Stock
| Dimensions | |
|---|---|
| Unit Length | 12 (in) |
| Unit Volume | .21 (ft³) |
| Unit Weight | 3 (lb) |
| Unit Width | 8.4 (in) |
| Unit Height | 3.6 (in) |
| Attributes | |
|---|---|
| Maximum Working Pressure | 1500 (psi) |
| Wetted Material | Aluminum;Stainless Steel;CS;Acetal;Nitrile Rubber;TPE |
| Minimum Operating Temperature | -40 (°C) |
| Minimum Operating Temperature | -40 (°F) |
| Outlet Size | 1.905 (cm) |
| Outlet Size | 3/4 (in) |
| Outlet Size | 19.05 (mm) |
| Outlet Thread Gender | Female |
| Outlet Thread Type | Straight Thread O-Ring Boss |
| Recommended Environment | Indoor;Outdoor |
| Trigger Lock | Locking |
| Type | Non-Metered Dispense Valve |
| Valve Type | Non-Metered |
| Weight | 0.18 (kg) |
| Weight | 0.4 (lb) |
| Maximum Working Pressure | 10340 (kPa) |
| Maximum Working Pressure | 103.4 (bar) |
| Maximum Operating Temperature | 180 (°F) |
| Maximum Operating Temperature | 82 (°C) |
| Inlet Thread Type | NPT |
| Inlet Thread Gender | Female |
| Inlet Size | 12.7 (mm) |
| Inlet Size | 1/2 (in) |
| Inlet Size | 1.27 (cm) |
| Includes | Nozzle, Extension |
| Extension Type | Gear Lube |
| Display Type | N/A |
| Dispense Type | Manual |
| Compatible Material | Gear Lube |
| Model | SDV15 |
| UPC Code | 00633955316478 |
