graco-247980-247980
graco-247980-247980

GRACO
247980

$33,020.00

Move large amounts of grease fast! Proven Graco NXT technology gives you the best value for the money - fewer parts, faster repairs and long-lasting durability.

  • GRACO
  • Material:247980
  • Model:CHECK-MATE SYSTEM,63:1,RAM
  • Summary:

    Move large amounts of grease fast! Proven Graco NXT technology gives you the best value for the money - fewer parts, faster repairs and long-lasting durability.

Factory Stock

Graco 247980 NXT™ Check-Mate® 63:1 RAM Grease Pump Package with DataTrak
  • Intuitive, easy-to-use controls give you pump diagnostics to track material usage and plan for routine maintenance
  • Long-lasting durability - Check-Mate pump is a time-tested, proven performer
  • Reduces icing and noise - The NXT air motor is up to 50% quieter than previous models
  • Integrated ram and pump control is easy to use

  • NXT Air Motor

    • Modular design for easier maintenance
    • Rugged body armor won't rust or dent
    • Highest technology air motor on the market

  • Integrated Air Controls

    • Lockable easy-turn regulator
    • Front-mounted for easy access
    • Compact and modular
    • Built-in filtration

  • Xtreme® Coupler

    • Quick-disconnect coupler for easy maintenance

  • Replaceable Outlet Fitting

    • Reduces repair costs

  • Piston Valve with Floating Piston Seal

    • For maximum pressure balance over a range of material viscosities

  • Replaceable Seat

    • Minimizes service costs

  • Floating Priming Plate

    • Provides uniform flow

  • Cast Outlet and Inlet Housing

    • Improves structural integrity

  • Unique Cartridge Throat Packings

    • Allows for easy servicing without removing from ram

  • DataTrak™ Control

    • Runaway protection
    • Pump diagnostics
    • Material tracking

  • Modular Air Valve

    • De-icing controls
    • Up to 50% quieter than previous models
    • Modular air valve - eliminates stalling, easy-to-repair

  • Hard Part Coatings

    • Standard Severe Duty™ coating on rods and cylinder maximizes wear life

Attributes
Includes 63:1 Check-Mate Pump with DataTrak;NXT 3400 Air Motor;100cc Lower;Ram;Air Hose;Fluid Hose
Wetted Material CS;Leather
Type Piston Pump Package
Pump Weight 35 (lb)
Mount Location Ram Mount
Motor Type Pneumatic
Maximum Working Pressure 4500 (psi)
Maximum Working Pressure 31 (MPa)
Maximum Working Pressure 3100 (kPa)
Maximum Working Pressure 310 (bar)
Maximum Fluid Working Pressure 4500 (psi)
Maximum Flow Rate 11.4 (lb/mi)
Maximum Air Working Pressure 100
UPC Code 00633955370449
Fluid Outlet Thread Type NPT
Fluid Outlet Thread Gender Male
Fluid Outlet Size 19.05 (mm)
Fluid Outlet Size 3/4 (in)
Fluid Outlet Size 1.905 (cm)
Compatible Material Grease
Application Industrial
Air Inlet Thread Type NPT
Air Inlet Thread Gender Female
Air Inlet Size 0.75 (in)
Model Check-Mate
