You can't afford down time, especially when your shop is small and your work force depends on equipment performance. The Mini Fire-Ball 225 is an engineered design with fewer moving parts, which means less wear out, and reduced downtime and more profit for your business.
Factory Stock
| Dimensions | |
|---|---|
| Unit Weight | 89.75 (lb) |
| Attributes | |
|---|---|
| Maximum Working Pressure | 3.7 (MPa) |
| Fluid Outlet Thread Type | NPT |
| Includes | Bung Adapter;Down Tube;SD Series Reel;Fluid Hose;Meter |
| Maximum Air Working Pressure | 180 |
| Maximum Flow Rate | 1.84 (gpm @) |
| Maximum Fluid Working Pressure | 540 (psi) |
| Maximum Working Pressure | 37 (bar) |
| Maximum Working Pressure | 3700 (kPa) |
| Fluid Outlet Size | 12.7 (mm) |
| Maximum Working Pressure | 540 (psi) |
| Motor Type | Pneumatic |
| Power Type | Pneumatic |
| Pump Ratio | 3:1 |
| Pump Weight | 16 (lb) |
| Type | Piston Pump Package |
| Wetted Material | Steel;Buna-N;Polyurethane;Aluminum;Rulon |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Size | 1/2 (in) |
| Fluid Outlet Size | 1.27 (cm) |
| Fluid Inlet Thread Type | NPT |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Size | 38.1000 (mm) |
| Fluid Inlet Size | 1.5 (in) |
| Fluid Inlet Size | 3.8100 (cm) |
| Compatible Material | Oil |
| Application | Industrial |
| Air Inlet Thread Type | NPT |
| Air Inlet Thread Gender | Female |
| Air Inlet Size | 0.375 (in) |
| Series | 225 |
| Model | Mini Fire-Ball |
| UPC Code | 00633955073623 |
