The GT 750 pump was engineered to perform in challenging applications and changing environments. The large 7.5-inch (190 mm) air motor and pump lower combination allows the GT 750 pump to move the same amount of grease with up to four times fewer pump strokes.
The GT 750 pump was engineered to perform in challenging applications and changing environments. The large 7.5-inch (190 mm) air motor and pump lower combination allows the GT 750 pump to move the same amount of grease with up to four times fewer pump strokes.
Factory Stock
Efficient Air Motor -Use less air to move more grease.
High Flow Rates - Up to 32 lb/min (13.6 kg/min) of grease.
High Volume Per Stroke - Pump more grease without having to drive pump too quickly to damage seals.
Proven Pump Technology - Based on Graco NXT™ pump technology.
Multiple Tank Options - Available in 35, 120 and 400 lb (16, 54 and 181 kg) down tube lengths.
| Dimensions | |
|---|---|
| Unit Length | 60 (in) |
| Unit Volume | 10.3125 (ft³) |
| Unit Weight | 79.2 (lb) |
| Unit Width | 16.5 (in) |
| Unit Height | 18 (in) |
| Attributes | |
|---|---|
| Includes | 2 Inch Bung Adapter and Lift Ring;400 lb (181 kg) Lower |
| Weight | 59 (lb) |
| Maximum Air Consumption | 130 (SCFM) |
| Maximum Air Inlet Pressure | 6.9 (bar) |
| Maximum Air Inlet Pressure | 690 (kPa) |
| Maximum Air Inlet Pressure | 100 (psi) |
| Maximum Continuous Cycle Rate | 60 (CPM) |
| Maximum Working Pressure | 248.2 (bar) |
| Maximum Working Pressure | 24820 (kPa) |
| Maximum Working Pressure | 24.8 (MPa) |
| Maximum Working Pressure | 3600 (psi) |
| Output Per Cycle | 180 (cm³) |
| Pump Ratio | 36:1 |
| Sound Power Level | 77.2 (dB) |
| Sound Pressure Level | 70.5 (dB) |
| Type | Pneumatic Piston Pump |
| Weight | 2.6786 (kg) |
| Application | Grease |
| UPC Code | 00633955695450 |
| Model | GT 750 |
| Air Inlet Size | 1.27 (cm) |
| Air Inlet Size | 0.5 (in) |
| Air Inlet Size | 12.7 (mm) |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Air Motor Effective Diameter | 7.5 (in) |
| For Use With | Grease up to NLGI 2 |
| Compatible Material | Grease |
| Fluid Inlet Thread Type | NPT |
| Fluid Inlet Type | NPT |
| Fluid Outlet Size | 2.54 (cm) |
| Fluid Outlet Size | 1 (in) |
| Fluid Outlet Size | 25.4 (mm) |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
