GRACO
24G738

Graco 24G738 SDI15 Series Medium/High Pressure – Medium/High Flow In-Line Meter for Diesel Exhaust Fluid Applications - BSPP

• Durable design for rugged, indoor use
• Easy to use – dispenses pints, quarts, liters or gallons
• 0.5 gpm to 15 gpm (1.9 lpm to 57 lpm) flow rate
• 1500 psi (103 bar) maximum pressure, 1/2 in NPT inlet

Typical applications include automotive and heavy-duty dealerships, service and fast lube centers, fleet service facilities and in-plant.

Dimensions
Unit Length	8.4 (in)
Unit Volume	.224 (ft³)
Unit Weight	2.8 (lb)
Unit Width	4.8 (in)
Unit Height	9.6 (in)

Attributes
Maximum Working Pressure	105 (bar)
Wetted Material	Stainless Steel;Fluoroelastomer;PBT
Maximum Working Pressure	10500 (kPa)
Maximum Working Pressure	10.5 (MPa)
Maximum Working Pressure	1500 (psi)
Meter Accuracy	±0.5
Meter Repeatability	±0.15 (%)
Minimum Operating Temperature	-20 (°C)
Minimum Operating Temperature	-4 (°F)
Type	Electronic In-Line Meter
Unit of Measure	Quart;Liter;Gallon;Pint
Weight	0.82 (kg)
Weight	1.8 (lb)
Maximum Operating Temperature	122 (°F)
Maximum Operating Temperature	50 (°C)
Maximum Flow Rate	57 (L/min)
Maximum Flow Rate	15 (GPM)
Inlet Thread Type	BSPP
Inlet Size	12.7 (mm)
Inlet Size	0.5 (in)
Inlet Size	1.27 (cm)
For Use With	Diesel Exhaust Fluid
Compatible Material	Diesel Exhaust Fluid
Battery Size	AA
Battery Chemistry	Alkaline
UPC Code	00633955600300
