The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.
The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.
The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.
The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.
Factory Stock
| Dimensions | |
|---|---|
| Unit Length | 10.8 (in) |
| Unit Volume | .63 (ft³) |
| Unit Weight | 8.5 (lb) |
| Unit Width | 8.4 (in) |
| Unit Height | 12 (in) |
| Attributes | |
|---|---|
| Maximum Fluid Pressure | 0.3 (MPa) |
| Manifold O-Ring Material | PTFE |
| Maximum Fluid Pressure | 340 (kPa) |
| Maximum Fluid Pressure | 3.4 (bar) |
| Maximum Flow Rate | 56.8 (L/min) |
| Maximum Flow Rate | 15 (GPM) |
| Maximum Cycle Rate | 400 (CPM) |
| Maximum Air Pressure | 50 (psi) |
| Maximum Air Pressure | 0.3 (MPa) |
| Maximum Air Pressure | 340 (kPa) |
| Maximum Air Pressure | 3.4 (bar) |
| Maximum Air Consumption | 28 (SCFM) |
| Wetted Material | Polypropylene;PTFE |
| Maximum Fluid Pressure | 50 (psi) |
| Maximum Operating Temperature | 66 (°C) |
| Maximum Operating Temperature | 150 (°F) |
| Maximum Solid Size | 0.2383 (cm) |
| Maximum Solid Size | 0.09375 (in) |
| Maximum Solid Size | 2.383 (mm) |
| Minimum Operating Temperature | 4 (°C) |
| Minimum Operating Temperature | 40 (°F) |
| Overall Height | 10.63 (in) |
| Power Source | Air |
| Seat Material | Polypropylene |
| Type | Pneumatic Diaphragm Pump |
| Weight | 6.5 (lb) |
| Connection Type | Threaded |
| UPC Code | 00633955600324 |
| Model | SD |
| Air Exhaust Port Size | 3/8 (in) |
| Air Exhaust Port Thread Gender | Female |
| Air Exhaust Port Thread Type | NPT |
| Air Inlet Size | 1/4 (in) |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Application | Industrial |
| Ball Material | Fluoroelastomer |
| Center Section Material | Polypropylene |
| Compatible Material | Diesel Exhaust Fluid |
| For Use With | DEF |
| Diaphragm Material | PTFE |
| Fluid Inlet Size | 1.905 (cm) |
| Fluid Inlet Size | 3/4 (in) |
| Fluid Inlet Size | 19.05 (mm) |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | BSPP |
| Fluid Outlet Size | 1.905 (cm) |
| Fluid Outlet Size | 3/4 (in) |
| Fluid Outlet Size | 19.05 (mm) |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | BSPP |
| Fluid Section Material | Polypropylene |
