graco-24H753-24H753
graco-24H753-24H753

GRACO
24H753

$3,300.00
  • Material:24H753
  • Model:KIT,3:1 CART W/ REEL-NPT
  • Summary:

    Stay ahead of the competition with LD Series pumps. These affordable and full-featured pumps are designed for lower-volume applications. LD pumps are fine-tuned for a compact, flexible and durable solution.

Factory Stock

Graco 24H753 LD Series 3:1 Mobile Oil Pump Package - Preset Meter Type
  • Three Inch Air Motor - Provides more power to create better flow.
  • Engineered for Durability - Patented cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
  • Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.
  • Pilot Valves - Patented self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
  • Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion, and an inlet strainer is built in to protect pump from contaminants.

Attributes
Maximum Air Working Pressure 150 (psi)
Wetted Material Zinc-Plated Carbon Steel;Aluminum;Nitrile;Polyurethane;Nickel-Plated Aluminum
Type Piston Pump Package
Pump Ratio 3:1
Power Type Pneumatic
Mount Location Cart Mount
Maximum Working Pressure 750 (psi)
Maximum Working Pressure 5.2 (MPa)
Maximum Working Pressure 5200 (kPa)
Maximum Working Pressure 52 (bar)
Maximum Flow Rate 7.8 (GPM)
UPC Code 00633955055872
Fluid Outlet Size 12.7 (mm)
Fluid Outlet Size 1/2 (in)
Fluid Outlet Size 1.27 (cm)
Fluid Inlet Size 25.4 (mm)
Fluid Inlet Size 1 (in)
Fluid Inlet Size 2.54 (cm)
Compatible Material Oil
Application Oil
Air Inlet Size 0.25 (in)
Model LD
