graco-24V679-24V679

GRACO
24V679

Price: $1,435.00

Sale: $1,219.75

Graco's SD Series DEF solutions are built on versatility with a Husky 515 AODD pump delivering up to 15 gpm (57 lpm) and operating on as little as 30 to 50 psi (2.1 to 3.4 bar). Increasing productivity this powerful pneumatic design provides superior suction and lift in tanks, totes and drums. Whether a small garage or large dealership, Graco has a complete line of Diesel Exhaust Fluid (DEF) for every application, capable of higher outputs over longer runs.

  • GRACO
  • Material:24V679
  • Model:SD BLUE DEF SYSTEM,AODD,DRUM,W/O METER
  • Summary:

    Graco's SD Series DEF solutions are built on versatility with a Husky 515 AODD pump delivering up to 15 gpm (57 lpm) and operating on as little as 30 to 50 psi (2.1 to 3.4 bar). Increasing productivity this powerful pneumatic design provides superior suction and lift in tanks, totes and drums. Whether a small garage or large dealership, Graco has a complete line of Diesel Exhaust Fluid (DEF) for every application, capable of higher outputs over longer runs.

Factory Stock

Graco 24V679 SD™ Blue Pump Drum Package - 2 ft (0.61 m) Suction Hose Length - Manual Nozzle - SST Clamp Fittings
  • Modular air valve with a stall-free, low-pulsation design for smooth and rapid changeover to increase efficiency and minimize downtime
  • Robust design with bolt-through fluid cover design to eliminate leaks and provide safety and reliability
  • Rugged construction built to resist corrosion for reliable performance and long life
  • High-efficiency air valves operate at a maximum of 28 scfm
  • Center and end porting options available
  • Up to 15 ft (4.57 m) of suction lift provides installation flexibility
  • 5 year warranty. See manufacturers website for details.
  • Package Includes: Husky 515 Diaphragm Pump (241906), Air Regulator (110147), Fluid Connect Hose (109105), Air Connect Hose (109125), Air Shut-Off Valve (110223), Mounting Bracket (224835), Suction Kit (236054), Thermal Relief Kit (238428) for Bulk Anti-Freeze and Windshield Solvent Transfer

Typical applications include automotive and heavy-duty dealerships, mining, service and fast lube centers, fleet service facilities, in-plant, and lube trucks.
Dimensions
Unit Length 24 (in)
Unit Volume 3.6667 (ft³)
Unit Weight 28.5 (lb)
Unit Width 24 (in)
Unit Height 11 (in)

Attributes
Inlet Size 3/4 (in)
Type Diaphragm Pump Package
Inlet Size 19.05 (mm)
Inlet Thread Gender Female
Inlet Thread Type BSPP
Maximum Air Pressure 4 (bar)
Maximum Air Pressure 40 (kPa)
Maximum Air Pressure 50 (psi)
Maximum Cycle Rate 400 (CPM)
Maximum Fluid Pressure 3.4 (bar)
Maximum Fluid Pressure 34 (kPa)
Maximum Fluid Pressure 0.35 (MPa)
Maximum Fluid Pressure 50 (psi)
Maximum Solid Size 0.2381 (cm)
Maximum Solid Size 0.09375 (in)
Maximum Solid Size 2.3813 (mm)
Mount Location Drum Mount
Fluid Inlet Thread Type BSPP
UPC Code 00633955688384
Model SD
Application Industrial
Compatible Material Diesel Exhaust Fluid
Fluid Inlet Size 1.9050 (cm)
Fluid Inlet Size 3/4 (in)
Fluid Inlet Size 19.05 (mm)
Fluid Inlet Thread Gender Female
Inlet Size 1.905 (cm)
Fluid Outlet Size 1.905 (cm)
Fluid Outlet Size 3/4 (in)
Fluid Outlet Size 19.05 (mm)
Fluid Outlet Thread Gender Female
Fluid Outlet Thread Type BSPP
For Use With DEF
Hose Length 2 (ft)
Includes Air Operated Diaphragm Pump;Mounting Bracket;LD Manual Nozzle;Dispense Hose and 2 Clamps;Suction Hose and 2 Clamps;Air Safety Valve
