graco-24Z126-24Z126

GRACO
24Z126

Price: $827.00

Sale: $702.95

Mechanical meters are ideal for indoor or outdoor use in all size shops, typically handling applications in automotive dealerships, fast lube centers, and service shops. The meter featured is fitted with a multiple nozzle and extension options and are capable of pumping oil up to 8 gpm (30.2 lpm).

  • GRACO
  • Material:24Z126
  • Model:METER, PRESET, 60 QRT, FLEX, NPT
  • Summary:

    Mechanical meters are ideal for indoor or outdoor use in all size shops, typically handling applications in automotive dealerships, fast lube centers, and service shops. The meter featured is fitted with a multiple nozzle and extension options and are capable of pumping oil up to 8 gpm (30.2 lpm).

Factory Stock

Graco 24Z126 60 Quart Preset Meter - Includes Nozzle/Extension Kit - Flexible Extension - NPT
  • Preset meter automatically shuts-off flow when preset quantity has been dispensed
  • Impact-resistant shroud resists against scratches and protects knob and dial from damage
  • Dial and face design made simple, easy to read and set
  • Durable aluminum cast housing is balanced and lightweight for a comfortable grip
  • Built-in totalizer to manage material usage
  • Inlet 1/2 in. NPT with swivel
  • Measures fluid in quarts
  • Features flexible extension with oil nozzle
  • 5 Year Warranty

Typical applications include Automotive dealerships, Heavy-duty dealerships, Fast lube centers, Fleet service facilities, In-plant, Lube trucks, and Mining.
Dimensions
Unit Length 14.25 (in)
Unit Volume .4005 (ft³)
Unit Weight 5.65 (lb)
Unit Width 9.25 (in)
Unit Height 5.25 (in)

Attributes
Meter Accuracy ±1%
Wetted Material Brass;Aluminum;Stainless Steel;TPE
Meter Pressure Loss 2 (bar)
Meter Pressure Loss 200 (kPa)
Meter Pressure Loss 30 (psi)
Metering Gun Weight 1.58 (kg)
Metering Gun Weight 3.5 (lb)
Minimum Operating Temperature -45 (°C)
Minimum Operating Temperature -50 (°F)
Nozzle Type Manual
Outlet Size 1.27 (cm)
Outlet Size 1/2 (in)
Outlet Size 12.7 (mm)
Outlet Thread Type NPT
Recommended Environment Indoor;Outdoor
Trigger Lock Locking
Type Mechanical Metered Dispense Valve
Valve Type Metered
Inlet Size 12.7 (mm)
UPC Code 00755652366379
Compatible Material Oil;Antifreeze
Dispense Type Preset
Display Type Mechanical
Extension Type Flexible
Includes Bare Meter;Nozzle Kit
Inlet Size 1.27 (cm)
Inlet Size 1/2 (in)
Maximum Working Pressure 1500 (psi)
Inlet Thread Type NPT
Maximum Flow Rate 8 (GPM)
Maximum Flow Rate 30 (L/min)
Maximum Operating Temperature 70 (°C)
Maximum Operating Temperature 160 (°F)
Maximum Working Pressure 103.4 (bar)
Maximum Working Pressure 10340 (kPa)
Maximum Working Pressure 10 (MPa)
