graco-25C454-25C454

GRACO
25C454

$3,540.00

Low shear, electric, direct drive agitator mixes and maintains suspension of industrial coatings stored in fluid tanks.

  • GRACO
  • Material:25C454
  • Model:AGITATOR,ASSY,DIRECT DRIVE
  • Summary:Low shear, electric, direct drive agitator mixes and maintains suspension of industrial coatings stored in fluid tanks.

Factory Stock

Graco 25C454 7.5 in OD Flange Mount Agitator Motor (3 in 150# ANSI Flange Mounting Holes), UL
  • Electric agitators are up to 5 times more efficient than pneumatic agitators.
  • Speed remains constant, regardless of material level in tank.
  • Low shear mixing ensures uniform particle dispersion without material degradation.

For advanced control and energy savings, switch to electric agitators.
Dimensions
Unit Length 21 (in)
Unit Volume 3.208333 (ft³)
Unit Weight 56 (lb)
Unit Width 16 (in)
Unit Height 16.5 (in)

Attributes
Wetted Material Stainless Steel
Weight Range 55-65 (lb)
Weight Range 25-30 (kg)
Type Agitator
Power Rating 0.37 (kW)
Power Rating 0.75 (HP)
Motor Type Electric
Minimum Operating Temperature 32 (°F)
Maximum Viscosity 300 (cP)
Maximum Speed 500 (RPM)
Maximum Operating Temperature 104 (°F)
Maximum Operating Temperature 40 (°C)
Includes Motor, Flange
For Use With Drum or Pressure Tank
UPC Code 00755652406235
